Mud gun directs high-pressure jets to suspend settled solids, clean tank bottoms, and assist homogenization in drilling fluid circulation.
TECHNICAL DATA
| Specification | JKZNJQ50-3 | JKZNJQ80-1 | JKZNJQ80-3 |
|---|---|---|---|
| Diameter:（） | DN50 | DN80 | DN80 |
| Nozzle Number | 3pcs | 1pcs | 3pcs |
| Working pressure（Mpa） | 1.6~6.4 | 1.6~6.4 | 1.6~6.4 |
| Rotation angle | 否 | 是 | 是 |
PRODUCT DETAILS
Effectively Blending and mixing the drilling fluids contains various of additives through impact force out of high pressure jet, mud gun plays important role to keep the stability of drilling fluids and prevent it’s dropping and depositing on the floor of mud tank.
Designed with efficient high pressure jet technique, JKZ made mud gun could evenly mix the various of ingredients and additives in drilling fluids and avoid of deposition can be regarded as essential equipment in drilling mud treatment.
