Mud gas separator removes entrained gas from drilling fluid, preventing gas kicks and maintaining mud weight, ensuring safe and efficient solids control.
TECHNICAL DATA
| Specification | JKZYQ800 | JKZYQ1000 | JKZYQ1200 |
|---|---|---|---|
| Tank diameter | 800 | 1000 | 1200 |
| Capability（m³/h） | 160-220 | 220-300 | 300-360 |
| Inlet size | 4" | 5" | 5" |
| Outlet size | 10" | 10" | 10" |
| Vent line size | 6" | 8" | 8" |
| Weight（KG） | 1950 | 2350 | 2750 |
| Mpa Pressure（Mpa） | 1~6.4 | 1~6.4 | 1~6.4 |
| Dimension（mm） | 2000*2000*5100 | 2400*2400*7827 | 2400*2400*8797 |
PRODUCT DETAILS
Separating gas from drilling fluids through gravity and particular inner structure, preventing gases input those equipment in following procedures, mud gas separator plays key role in separating gas out of drilling fluids, and help to keep stable performance of the drilling fluids and secure safe operation.
JKZ made mud gas separator adopts efficient separation technology, which can quickly separate various gases and prevent gas invasion. It is an indispensable mud treatment equipment in drilling.
